Product Advantages
- Multi-channel parallel optical transmission
- Optical fiber cutting length: 100~1000um, tolerance: ±10um;（>1000um, tolerance: ±20um）
- Optical fiber cutting angle: 0~45°, tolerance: ±1°
- High-precision control ability of FA fiber core offset distance.
- Support customized optical component design (FA size and structure, fiber cutting length and direction)
Product Specs
| Parameter Item | Specification Value |
|---|---|
| Operating Wavelength | 850~1620nm |
| Optical Fiber Type | G.657A1/G.657A2/OM3/OM4 |
| Operating Temperature | -20~70℃ |
| Fiber Core Offset Distance | 127/250um |
| Grinding Angle | 8°/12°/42.5°/45°, tolerance: ±0.5° |
| Core Pitch Error (For polish type) | 1ch: \ 2ch: 0.3um 4ch: 0.5um 8ch: 0.5um 16ch: 0.8um 24ch: 1um |
| V-groove Material | SiO2 or Borosilicate |
| V-groove Specification | (3–10)°/(2–5)°/(1–2)mm |
